library(duckdb)
library(CDMConnector)
library(dplyr)
library(tidyr)
library(DBI)
library(here)
datasetName <- "GiBleed"
dbdir <- here(paste0(datasetName, ".duckdb"))
con <- dbConnect(drv = duckdb(dbdir = dbdir))
cdm <- cdmFromCon(
con = con,
cdmSchema = "main",
writeSchema = "main",
writePrefix = "cg_",
cdmName = datasetName
)CodelistGenerator
Working with the OMOP CDM vocabulary tables
2025-06-26
CodelistGenerator
Reference to the CDM vocabulary tables
Reference to the CDM vocabulary tables
cdm── # OMOP CDM reference (duckdb) of GiBleed ──────────────────────────────────────────────────────────────────────────────────────• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship, location,
care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source, concept, vocabulary,
domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor, source_to_concept_map,
drug_strength• cohort tables: -• achilles tables: -• other tables: -Reference to the CDM vocabulary tables
Note, Eunomia doesn´t have a full set of vocabularies:
We’ll create a mock to show some of the functions where Eunomia won’t work because of its partial vocabularies
library(CodelistGenerator)
cdm_mock <- mockVocabRef()
cdm_mockCDM vocabulary tables
CDM vocabulary tables
CDM vocabulary tables
Rows: ??
Columns: 10
Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
$ concept_id <int> 35208414, 1118088, 40213201, 1557272, 4336464, 4295880, 3020630, 19129655, 44923712, 1569708, 40213216,…
$ concept_name <chr> "Gastrointestinal hemorrhage, unspecified", "celecoxib 200 MG Oral Capsule [Celebrex]", "pneumococcal p…
$ domain_id <chr> "Condition", "Drug", "Drug", "Drug", "Procedure", "Procedure", "Measurement", "Drug", "Drug", "Conditio…
$ vocabulary_id <chr> "ICD10CM", "RxNorm", "CVX", "RxNorm", "SNOMED", "SNOMED", "LOINC", "RxNorm", "NDC", "ICD10CM", "CVX", "…
$ concept_class_id <chr> "4-char billing code", "Branded Drug", "CVX", "Ingredient", "Procedure", "Procedure", "Lab Test", "Clin…
$ standard_concept <chr> NA, "S", "S", "S", "S", "S", "S", "S", NA, NA, "S", "S", "S", "S", "S", "S", NA, "S", "S", "S", "S", "S…
$ concept_code <chr> "K92.2", "213469", "33", "46041", "232717009", "76601001", "2885-2", "789980", "00025152531", "K92", "1…
$ valid_start_date <date> 2007-01-01, 1970-01-01, 2008-12-01, 1970-01-01, 1970-01-01, 1970-01-01, 1970-01-01, 2008-03-30, 2000-0…
$ valid_end_date <date> 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31, 2099-1…
$ invalid_reason <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…CDM vocabulary tables
cdm$condition_occurrence %>%
group_by(condition_concept_id) %>%
tally() %>%
left_join(
cdm$concept %>%
select("concept_id", "concept_name"),
by = c("condition_concept_id" = "concept_id")
) %>%
collect() %>%
arrange(desc(n))# A tibble: 80 × 3
condition_concept_id n concept_name
<int> <dbl> <chr>
1 40481087 17268 Viral sinusitis
2 4112343 10217 Acute viral pharyngitis
3 260139 8184 Acute bronchitis
4 372328 3605 Otitis media
5 80180 2694 Osteoarthritis
6 28060 2656 Streptococcal sore throat
7 81151 1915 Sprain of ankle
8 378001 1013 Concussion with no loss of consciousness
9 4283893 1001 Sinusitis
10 4294548 939 Acute bacterial sinusitis
# ℹ 70 more rowsCDM vocabulary tables
Rows: ??
Columns: 4
Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
$ ancestor_concept_id <int> 4180628, 4179141, 21500574, 21505770, 21503967, 36203060, 36151386, 21502552, 40765628, 4433964…
$ descendant_concept_id <int> 313217, 4146173, 1118084, 1119510, 40162522, 40479422, 1119510, 1112807, 40769189, 19128009, 15…
$ min_levels_of_separation <int> 5, 2, 4, 0, 5, 4, 0, 4, 2, 2, 0, 0, 0, 0, 0, 0, 0, 0, 2, 0, 0, 2, 2, 0, 0, 2, 0, 0, 0, 0, 0, 0,…
$ max_levels_of_separation <int> 6, 2, 4, 0, 6, 4, 0, 4, 2, 2, 0, 0, 0, 0, 0, 0, 0, 0, 3, 0, 0, 3, 3, 0, 0, 3, 0, 0, 0, 0, 0, 0,…CDM vocabulary tables
Rows: ??
Columns: 6
Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
$ concept_id_1 <int> 192671, 1118088, 1569708, 35208414, 35208414, 40162359, 44923712, 45011828
$ concept_id_2 <int> 35208414, 44923712, 35208414, 192671, 1569708, 45011828, 1118088, 40162359
$ relationship_id <chr> "Mapped from", "Mapped from", "Subsumes", "Maps to", "Is a", "Mapped from", "Maps to", "Maps to"
$ valid_start_date <date> 1970-01-01, 1970-01-01, 2016-03-25, 1970-01-01, 2016-03-25, 2009-08-03, 1970-01-01, 2009-08-03
$ valid_end_date <date> 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31, 2099-12-31
$ invalid_reason <chr> NA, NA, NA, NA, NA, NA, NA, NACDM vocabulary tables
Rows: ??
Columns: 3
Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
$ concept_id <int> 964261, 1322184, 441267, 1718412, 4336464, 4102123, 4237458, 4280726, 4330583, 3014576, 4242997, 30…
$ concept_synonym_name <chr> "cyanocobalamin 5000 MCG/ML Injectable Solution", "clopidogrel", "Cystic fibrosis (disorder)", "Kyl…
$ language_concept_id <int> 4180186, 4180186, 4180186, 4180186, 4180186, 4180186, 4180186, 4180186, 4180186, 4180186, 4180186, …Exploring vocabulary tables using CodelistGenerator
Vocabulary version
Search results will be specific to the version of the vocabulary being used
getVocabVersion(cdm = cdm)[1] "v5.0 18-JAN-19"Available vocabularies
What vocabularies are available?
getVocabularies(cdm = cdm)[1] "CVX" "Gender" "ICD10CM" "LOINC" "NDC" "None" "RxNorm" "SNOMED" "Visit" Available domains
What domains are present?
getDomains(cdm = cdm)[1] "Drug" "Measurement" "Observation" "Visit" "Gender" "Procedure" "Condition" Concept classes
What concept classes are present?
getConceptClassId(
cdm = cdm,
standardConcept = "Standard",
domain = "Drug"
)[1] "Branded Drug" "Branded Drug Comp" "Branded Pack" "Clinical Drug" "Clinical Drug Comp"
[6] "CVX" "Ingredient" "Quant Branded Drug" "Quant Clinical Drug"getConceptClassId(
cdm = cdm,
standardConcept = "Standard",
domain = "Condition"
)[1] "Clinical Finding"Relationship ID
What relationships do we have between standard concepts?
getRelationshipId(
cdm = cdm_mock,
standardConcept1 = c("standard"),
standardConcept2 = c("standard"),
domains1 = "condition",
domains2 = "condition"
)[1] "Due to of"What relationships do we have between non-standard to standard concepts?
getRelationshipId(
cdm = cdm_mock,
standardConcept1 = c("standard"),
standardConcept2 = c("non-standard"),
domains1 = "condition",
domains2 = "condition"
)[1] "Mapped from"Drug dose forms
getDoseForm(cdm = cdm_mock)[1] "Injectable" "Injection" "Nasal Powder" "Topical Liquefied Gas"Your turn
Using a cdm reference you have connected to:
What is the vocabulary version of the cdm?
How many concepts are in your concept table? How many of these are standard concepts?
What domains are available? Which domains would you use if you were defining a cohort of people with asthma?
Solution
💡 Click to see solution
getVocabVersion(cdm = cdm)
cdm$concept |>
tally()
getDomains(cdm = cdm)Vocabulary based codelists using CodelistGenerator
Vocabulary-based codelists using CodelistGenerator
We can use drug hierarchies and relationships to create vocabulary-based codelists.
Drug ingredients
ingredients <- getDrugIngredientCodes(cdm = cdm, nameStyle = "{concept_name}")
ingredients
- acetaminophen (7 codes)
- albuterol (2 codes)
- alendronate (2 codes)
- alfentanil (1 codes)
- alteplase (2 codes)
- amiodarone (2 codes)
along with 85 more codelistsingredients$warfarin[1] 1310149 40163554# Source: SQL [?? x 10]
# Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
concept_id concept_name domain_id vocabulary_id concept_class_id standard_concept concept_code valid_start_date valid_end_date
<int> <chr> <chr> <chr> <chr> <chr> <chr> <date> <date>
1 1310149 Warfarin Drug RxNorm Ingredient S 11289 1970-01-01 2099-12-31
2 40163554 Warfarin Sodi… Drug RxNorm Clinical Drug S 855332 2009-08-02 2099-12-31
# ℹ 1 more variable: invalid_reason <chr>ATC classifications
atc <- getATCCodes(cdm = cdm_mock, nameStyle = "{concept_name}")
atc
- alimentary_tract_and_metabolism (2 codes)atc$alimentary_tract_and_metabolism[1] 12 13ICD10 chapters
icd <- getICD10StandardCodes(cdm = cdm_mock, nameStyle = "{concept_name}")
icd
- arthropathies (3 codes)
- diseases_of_the_musculoskeletal_system_and_connective_tissue (3 codes)icd$arthropathies[1] 3 4 5Your turn
Using Eunomia data:
Get codes for memantine using
getDrugIngredientCodes. How many codes do you include?-
How how many records for memantine are in the drug exposure table (hint: filter on the drug_concept_id field from the drug_exposure table)?
0
67
110
245
Solution
💡 Click to see solution
memantine_codes <- getDrugIngredientCodes(cdm = cdm, name = "memantine")
memantine_codes
cdm$drug_exposure |>
filter(drug_concept_id %in% !!memantine_codes[[1]]) |>
tally()Systematic search using CodelistGenerator
Systematic search using CodelistGenerator
CodelistGenerator is used to create a candidate set of codes for helping to define patient cohorts in data mapped to the OMOP common data model.
A little like the process for a systematic review, the idea is that for a specified search strategy, CodelistGenerator will identify a set of concepts that may be relevant, with these then being screened to remove any irrelevant codes.
Codes for asthma
asthma_codes <- getCandidateCodes(
cdm = cdm,
keywords = "asthma",
domains = "Condition"
)
asthma_codes %>% glimpse()Rows: 2
Columns: 6
$ concept_id <int> 4051466, 317009
$ found_from <chr> "From initial search", "From initial search"
$ concept_name <chr> "Childhood asthma", "Asthma"
$ domain_id <chr> "Condition", "Condition"
$ vocabulary_id <chr> "SNOMED", "SNOMED"
$ standard_concept <chr> "S", "S"asthma_cs <- newCodelist(list("asthma" = asthma_codes$concept_id))
asthma_cs
- asthma (2 codes)Your turn
Using Eunomia data:
Search for codes for sinusitis recorded in the condition domain
Do you identify any more codes if you also search in the observation domain as well as the condition domain
Solution
💡 Click to see solution
sinusitis_codes <- getCandidateCodes(
cdm = cdm,
keywords = "sinusitis",
domains = "Condition"
)
nrow(sinusitis_codes)
sinusitis_codes_2 <- getCandidateCodes(
cdm = cdm,
keywords = "sinusitis",
domains = c("Condition", "Observation")
)
nrow(sinusitis_codes_2)Codelist diagnostics
Code counts
library(omopgenerics)
asthma_code_use <- summariseCodeUse(
x = asthma_cs,
byYear = TRUE,
bySex = TRUE,
ageGroup = list(
c(0, 17),
c(18, 65),
c(66, 150)
),
cdm = cdm
) |>
suppress(minCellCount = 5)
tableCodeUse(result = asthma_code_use |>
filter(strata_name == "overall"))
Database name
|
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
GiBleed
|
|||||||||||
| Codelist name | Year | Sex | Age group | Standard concept name | Standard concept ID | Source concept name | Source concept ID | Source concept value | Domain ID |
Estimate name
|
|
| Record count | Person count | ||||||||||
| asthma | overall | overall | overall | overall | - | NA | NA | NA | NA | 101 | 101 |
| Asthma | 317009 | Asthma | 317009 | 195967001 | condition | 5 | 5 | ||||
| Childhood asthma | 4051466 | Childhood asthma | 4051466 | 233678006 | condition | 96 | 96 | ||||
Code counts
tableCodeUse(result = asthma_code_use |>
filter(
strata_name == "year",
strata_level %in% c("2004", "2005", "2006")
))
Database name
|
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
GiBleed
|
|||||||||||
| Codelist name | Year | Sex | Age group | Standard concept name | Standard concept ID | Source concept name | Source concept ID | Source concept value | Domain ID |
Estimate name
|
|
| Record count | Person count | ||||||||||
| asthma | 2004 | overall | overall | overall | - | NA | NA | NA | NA | <5 | <5 |
| 2006 | overall | overall | overall | - | NA | NA | NA | NA | <5 | <5 | |
| 2004 | overall | overall | Asthma | 317009 | Asthma | 317009 | 195967001 | condition | <5 | <5 | |
| 2006 | overall | overall | Asthma | 317009 | Asthma | 317009 | 195967001 | condition | <5 | <5 | |
Code counts
tableCodeUse(result = asthma_code_use |>
filter(strata_name == "age_group"))
Database name
|
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
GiBleed
|
|||||||||||
| Codelist name | Year | Sex | Age group | Standard concept name | Standard concept ID | Source concept name | Source concept ID | Source concept value | Domain ID |
Estimate name
|
|
| Record count | Person count | ||||||||||
| asthma | overall | overall | 0 to 17 | overall | - | NA | NA | NA | NA | 96 | 96 |
| 18 to 65 | overall | - | NA | NA | NA | NA | 5 | 5 | |||
| Asthma | 317009 | Asthma | 317009 | 195967001 | condition | 5 | 5 | ||||
| 0 to 17 | Childhood asthma | 4051466 | Childhood asthma | 4051466 | 233678006 | condition | 96 | 96 | |||
Your turn
Using Eunomia data:
Identify codes for appendicitis from the condition domain
Make a table with counts of the usage of these codes
Solution
💡 Click to see solution
appendicitis_codes <- getCandidateCodes(
cdm = cdm,
keywords = "appendicitis",
domains = "Condition"
)
tableCodeUse(result = appendicitis)CodelistGenerator
Real World Evidence Summer School 2025
