OMOP and CDMConnector

The OMOP Common Data Model

2025-06-26

Introduction: The OMOP Common Data Model

Every time that someone goes to the doctor and something happens the doctors write it into their records.
Each annotation of the doctor is translated into a code, combination of letters and numbers that refers to a condition. There exist several different codding languages: SNOMED, read codes, ICD10, ICD9, RxNorm, ATC, … It depends on the region, language, type of record and others which one is used. This makes that the same condition or drug can be coded in different ways.
A compilation of these records for a group of people is what we call the medical databases. Depending on the origin and purpose of these data there are different groups of databases: electronic health records, claims data, registries… This databases can be structured by several different tables.
The Observational Medical Outcomes Partnership (OMOP) Common Data Model (CDM) is an open community data standard, designed to standardise the structure and content of observational data and to enable efficient analyses that can produce reliable evidence.

Standarisation of the data format

Tables and relation in the OMOP Common Data Model

Mapping a database to the OMOP CDM

Mapping process

Mapping a database to the OMOP CDM

Mapping process

Mapping a database to the OMOP CDM

Mapping process

Standarisation of the vocabularies

From all the vocabularies OMOP CDM uses only a few as Standard: SNOMED for conditions, RxNorm for drugs, …

The process to obtain an standard code from non standard one is called mapping. We can find the mapping in the concept_relationship table.

Each one of the records in clinical data tables (condition_occurrence, drug_exposure, measurement, observation, …) will be coded by two codes:

Source concept: particular to each database, it is the original code.
Standard concept: equivalent code from the standard vocabulary.

Example of mapping

In concept relationship we can find different information such as:

Concept relationship

In particular, we have the Maps to and Mapped from relations that can help us to see the mapping between codes.

Example of mapping

Mapping process

Example of mapping

Mapping process

Example of mapping

Mapping process

More details

For more details on how the vocabularies work you can check: Vocabulary course in EHDEN academy

All details about OMOP CDM and more can be found in: the book of ohdsi.

Let’s start coding

These are the packages that we will use in this presentation:

library(omock)
library(DBI)
library(CDMConnector)
library(duckdb)
library(here)
library(dplyr)
library(visOmopResults)
library(omopgenerics)

You can click on the specific functions to see ?help and what package they come from:

cdmFromCon()

Create a mock reference

You can create a mock database using omock from one of the 24 available synthetic databases:

availableMockDatasets()

 [1] "GiBleed"                             "empty_cdm"                           "synpuf-1k_5.3"
 [4] "synpuf-1k_5.4"                       "synthea-allergies-10k"               "synthea-anemia-10k"
 [7] "synthea-breast_cancer-10k"           "synthea-contraceptives-10k"          "synthea-covid19-10k"
[10] "synthea-covid19-200k"                "synthea-dermatitis-10k"              "synthea-heart-10k"
[13] "synthea-hiv-10k"                     "synthea-lung_cancer-10k"             "synthea-medications-10k"
[16] "synthea-metabolic_syndrome-10k"      "synthea-opioid_addiction-10k"        "synthea-rheumatoid_arthritis-10k"
[19] "synthea-snf-10k"                     "synthea-surgery-10k"                 "synthea-total_joint_replacement-10k"
[22] "synthea-veteran_prostate_cancer-10k" "synthea-veterans-10k"                "synthea-weight_loss-10k"

cdm <- mockCdmFromDataset(datasetName = "GiBleed")

ℹ Reading GiBleed tables.
ℹ Adding drug_strength table.

cdm


── # OMOP CDM reference (local) of GiBleed ─────────────────────────────────────────────────────────────────────────────
• omop tables: care_site, cdm_source, concept_ancestor, concept_class, concept_relationship, concept_synonym, concept,
condition_era, condition_occurrence, cost, death, device_exposure, domain, dose_era, drug_era, drug_exposure,
drug_strength, fact_relationship, location, measurement, metadata, note_nlp, note, observation_period, observation,
payer_plan_period, person, procedure_occurrence, provider, relationship, source_to_concept_map, specimen, visit_detail,
visit_occurrence, vocabulary
• cohort tables: -
• achilles tables: -
• other tables: -

`<cdm_reference>` object

class(cdm)

[1] "cdm_reference"

cdmName(cdm)

[1] "GiBleed"

cdmVersion(cdm)

[1] "5.3"

cdmSource(cdm)

This is a local cdm source

`<cdm_reference>` object

attributes(cdm)

$names
 [1] "care_site"             "cdm_source"            "concept_ancestor"      "concept_class"
 [5] "concept_relationship"  "concept_synonym"       "concept"               "condition_era"
 [9] "condition_occurrence"  "cost"                  "death"                 "device_exposure"
[13] "domain"                "dose_era"              "drug_era"              "drug_exposure"
[17] "drug_strength"         "fact_relationship"     "location"              "measurement"
[21] "metadata"              "note_nlp"              "note"                  "observation_period"
[25] "observation"           "payer_plan_period"     "person"                "procedure_occurrence"
[29] "provider"              "relationship"          "source_to_concept_map" "specimen"
[33] "visit_detail"          "visit_occurrence"      "vocabulary"

$cdm_name
[1] "GiBleed"

$cdm_source

This is a local cdm source


$cdm_version
[1] "5.3"

$class
[1] "cdm_reference"

`<cdm_table>` object

cdm$person

# A tibble: 2,694 × 18
   person_id gender_concept_id year_of_birth month_of_birth day_of_birth birth_datetime      race_concept_id
 *     <int>             <int>         <int>          <int>        <int> <dttm>                        <int>
 1         6              8532          1963             12           31 1963-12-31 00:00:00            8516
 2       123              8507          1950              4           12 1950-04-12 00:00:00            8527
 3       129              8507          1974             10            7 1974-10-07 00:00:00            8527
 4        16              8532          1971             10           13 1971-10-13 00:00:00            8527
 5        65              8532          1967              3           31 1967-03-31 00:00:00            8516
 6        74              8532          1972              1            5 1972-01-05 00:00:00            8527
 7        42              8532          1909             11            2 1909-11-02 00:00:00            8527
 8       187              8507          1945              7           23 1945-07-23 00:00:00            8527
 9        18              8532          1965             11           17 1965-11-17 00:00:00            8527
10       111              8532          1975              5            2 1975-05-02 00:00:00            8527
# ℹ 2,684 more rows
# ℹ 11 more variables: ethnicity_concept_id <int>, location_id <int>, provider_id <int>, care_site_id <int>,
#   person_source_value <chr>, gender_source_value <chr>, gender_source_concept_id <int>, race_source_value <chr>,
#   race_source_concept_id <int>, ethnicity_source_value <chr>, ethnicity_source_concept_id <int>

class(cdm$person)

[1] "omop_table" "cdm_table"  "tbl_df"     "tbl"        "data.frame"

`<cdm_table>` object

cdmReference(cdm$person)

── # OMOP CDM reference (local) of GiBleed ─────────────────────────────────────────────────────────────────────────────

• omop tables: care_site, cdm_source, concept_ancestor, concept_class, concept_relationship, concept_synonym, concept,
condition_era, condition_occurrence, cost, death, device_exposure, domain, dose_era, drug_era, drug_exposure,
drug_strength, fact_relationship, location, measurement, metadata, note_nlp, note, observation_period, observation,
payer_plan_period, person, procedure_occurrence, provider, relationship, source_to_concept_map, specimen, visit_detail,
visit_occurrence, vocabulary

• cohort tables: -

• achilles tables: -

• other tables: -

tableName(cdm$person)

[1] "person"

tableSource(cdm$person)

This is a local cdm source

`<cdm_table>` object

cdmName(cdm$person)

[1] "GiBleed"

cdmVersion(cdm$person)

[1] "5.3"

cdmSource(cdm$person)

This is a local cdm source

`<cdm_table>` object

attributes(cdm$person)

$class
[1] "omop_table" "cdm_table"  "tbl_df"     "tbl"        "data.frame"

$row.names
   [1]    1    2    3    4    5    6    7    8    9   10   11   12   13   14   15   16   17   18   19   20   21   22
  [23]   23   24   25   26   27   28   29   30   31   32   33   34   35   36   37   38   39   40   41   42   43   44
  [45]   45   46   47   48   49   50   51   52   53   54   55   56   57   58   59   60   61   62   63   64   65   66
  [67]   67   68   69   70   71   72   73   74   75   76   77   78   79   80   81   82   83   84   85   86   87   88
  [89]   89   90   91   92   93   94   95   96   97   98   99  100  101  102  103  104  105  106  107  108  109  110
 [111]  111  112  113  114  115  116  117  118  119  120  121  122  123  124  125  126  127  128  129  130  131  132
 [133]  133  134  135  136  137  138  139  140  141  142  143  144  145  146  147  148  149  150  151  152  153  154
 [155]  155  156  157  158  159  160  161  162  163  164  165  166  167  168  169  170  171  172  173  174  175  176
 [177]  177  178  179  180  181  182  183  184  185  186  187  188  189  190  191  192  193  194  195  196  197  198
 [199]  199  200  201  202  203  204  205  206  207  208  209  210  211  212  213  214  215  216  217  218  219  220
 [221]  221  222  223  224  225  226  227  228  229  230  231  232  233  234  235  236  237  238  239  240  241  242
 [243]  243  244  245  246  247  248  249  250  251  252  253  254  255  256  257  258  259  260  261  262  263  264
 [265]  265  266  267  268  269  270  271  272  273  274  275  276  277  278  279  280  281  282  283  284  285  286
 [287]  287  288  289  290  291  292  293  294  295  296  297  298  299  300  301  302  303  304  305  306  307  308
 [309]  309  310  311  312  313  314  315  316  317  318  319  320  321  322  323  324  325  326  327  328  329  330
 [331]  331  332  333  334  335  336  337  338  339  340  341  342  343  344  345  346  347  348  349  350  351  352
 [353]  353  354  355  356  357  358  359  360  361  362  363  364  365  366  367  368  369  370  371  372  373  374
 [375]  375  376  377  378  379  380  381  382  383  384  385  386  387  388  389  390  391  392  393  394  395  396
 [397]  397  398  399  400  401  402  403  404  405  406  407  408  409  410  411  412  413  414  415  416  417  418
 [419]  419  420  421  422  423  424  425  426  427  428  429  430  431  432  433  434  435  436  437  438  439  440
 [441]  441  442  443  444  445  446  447  448  449  450  451  452  453  454  455  456  457  458  459  460  461  462
 [463]  463  464  465  466  467  468  469  470  471  472  473  474  475  476  477  478  479  480  481  482  483  484
 [485]  485  486  487  488  489  490  491  492  493  494  495  496  497  498  499  500  501  502  503  504  505  506
 [507]  507  508  509  510  511  512  513  514  515  516  517  518  519  520  521  522  523  524  525  526  527  528
 [529]  529  530  531  532  533  534  535  536  537  538  539  540  541  542  543  544  545  546  547  548  549  550
 [551]  551  552  553  554  555  556  557  558  559  560  561  562  563  564  565  566  567  568  569  570  571  572
 [573]  573  574  575  576  577  578  579  580  581  582  583  584  585  586  587  588  589  590  591  592  593  594
 [595]  595  596  597  598  599  600  601  602  603  604  605  606  607  608  609  610  611  612  613  614  615  616
 [617]  617  618  619  620  621  622  623  624  625  626  627  628  629  630  631  632  633  634  635  636  637  638
 [639]  639  640  641  642  643  644  645  646  647  648  649  650  651  652  653  654  655  656  657  658  659  660
 [661]  661  662  663  664  665  666  667  668  669  670  671  672  673  674  675  676  677  678  679  680  681  682
 [683]  683  684  685  686  687  688  689  690  691  692  693  694  695  696  697  698  699  700  701  702  703  704
 [705]  705  706  707  708  709  710  711  712  713  714  715  716  717  718  719  720  721  722  723  724  725  726
 [727]  727  728  729  730  731  732  733  734  735  736  737  738  739  740  741  742  743  744  745  746  747  748
 [749]  749  750  751  752  753  754  755  756  757  758  759  760  761  762  763  764  765  766  767  768  769  770
 [771]  771  772  773  774  775  776  777  778  779  780  781  782  783  784  785  786  787  788  789  790  791  792
 [793]  793  794  795  796  797  798  799  800  801  802  803  804  805  806  807  808  809  810  811  812  813  814
 [815]  815  816  817  818  819  820  821  822  823  824  825  826  827  828  829  830  831  832  833  834  835  836
 [837]  837  838  839  840  841  842  843  844  845  846  847  848  849  850  851  852  853  854  855  856  857  858
 [859]  859  860  861  862  863  864  865  866  867  868  869  870  871  872  873  874  875  876  877  878  879  880
 [881]  881  882  883  884  885  886  887  888  889  890  891  892  893  894  895  896  897  898  899  900  901  902
 [903]  903  904  905  906  907  908  909  910  911  912  913  914  915  916  917  918  919  920  921  922  923  924
 [925]  925  926  927  928  929  930  931  932  933  934  935  936  937  938  939  940  941  942  943  944  945  946
 [947]  947  948  949  950  951  952  953  954  955  956  957  958  959  960  961  962  963  964  965  966  967  968
 [969]  969  970  971  972  973  974  975  976  977  978  979  980  981  982  983  984  985  986  987  988  989  990
 [991]  991  992  993  994  995  996  997  998  999 1000 1001 1002 1003 1004 1005 1006 1007 1008 1009 1010 1011 1012
[1013] 1013 1014 1015 1016 1017 1018 1019 1020 1021 1022 1023 1024 1025 1026 1027 1028 1029 1030 1031 1032 1033 1034
[1035] 1035 1036 1037 1038 1039 1040 1041 1042 1043 1044 1045 1046 1047 1048 1049 1050 1051 1052 1053 1054 1055 1056
[1057] 1057 1058 1059 1060 1061 1062 1063 1064 1065 1066 1067 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078
[1079] 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 1097 1098 1099 1100
[1101] 1101 1102 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122
[1123] 1123 1124 1125 1126 1127 1128 1129 1130 1131 1132 1133 1134 1135 1136 1137 1138 1139 1140 1141 1142 1143 1144
[1145] 1145 1146 1147 1148 1149 1150 1151 1152 1153 1154 1155 1156 1157 1158 1159 1160 1161 1162 1163 1164 1165 1166
[1167] 1167 1168 1169 1170 1171 1172 1173 1174 1175 1176 1177 1178 1179 1180 1181 1182 1183 1184 1185 1186 1187 1188
[1189] 1189 1190 1191 1192 1193 1194 1195 1196 1197 1198 1199 1200 1201 1202 1203 1204 1205 1206 1207 1208 1209 1210
[1211] 1211 1212 1213 1214 1215 1216 1217 1218 1219 1220 1221 1222 1223 1224 1225 1226 1227 1228 1229 1230 1231 1232
[1233] 1233 1234 1235 1236 1237 1238 1239 1240 1241 1242 1243 1244 1245 1246 1247 1248 1249 1250 1251 1252 1253 1254
[1255] 1255 1256 1257 1258 1259 1260 1261 1262 1263 1264 1265 1266 1267 1268 1269 1270 1271 1272 1273 1274 1275 1276
[1277] 1277 1278 1279 1280 1281 1282 1283 1284 1285 1286 1287 1288 1289 1290 1291 1292 1293 1294 1295 1296 1297 1298
[1299] 1299 1300 1301 1302 1303 1304 1305 1306 1307 1308 1309 1310 1311 1312 1313 1314 1315 1316 1317 1318 1319 1320
[1321] 1321 1322 1323 1324 1325 1326 1327 1328 1329 1330 1331 1332 1333 1334 1335 1336 1337 1338 1339 1340 1341 1342
[1343] 1343 1344 1345 1346 1347 1348 1349 1350 1351 1352 1353 1354 1355 1356 1357 1358 1359 1360 1361 1362 1363 1364
[1365] 1365 1366 1367 1368 1369 1370 1371 1372 1373 1374 1375 1376 1377 1378 1379 1380 1381 1382 1383 1384 1385 1386
[1387] 1387 1388 1389 1390 1391 1392 1393 1394 1395 1396 1397 1398 1399 1400 1401 1402 1403 1404 1405 1406 1407 1408
[1409] 1409 1410 1411 1412 1413 1414 1415 1416 1417 1418 1419 1420 1421 1422 1423 1424 1425 1426 1427 1428 1429 1430
[1431] 1431 1432 1433 1434 1435 1436 1437 1438 1439 1440 1441 1442 1443 1444 1445 1446 1447 1448 1449 1450 1451 1452
[1453] 1453 1454 1455 1456 1457 1458 1459 1460 1461 1462 1463 1464 1465 1466 1467 1468 1469 1470 1471 1472 1473 1474
[1475] 1475 1476 1477 1478 1479 1480 1481 1482 1483 1484 1485 1486 1487 1488 1489 1490 1491 1492 1493 1494 1495 1496
[1497] 1497 1498 1499 1500 1501 1502 1503 1504 1505 1506 1507 1508 1509 1510 1511 1512 1513 1514 1515 1516 1517 1518
[1519] 1519 1520 1521 1522 1523 1524 1525 1526 1527 1528 1529 1530 1531 1532 1533 1534 1535 1536 1537 1538 1539 1540
[1541] 1541 1542 1543 1544 1545 1546 1547 1548 1549 1550 1551 1552 1553 1554 1555 1556 1557 1558 1559 1560 1561 1562
[1563] 1563 1564 1565 1566 1567 1568 1569 1570 1571 1572 1573 1574 1575 1576 1577 1578 1579 1580 1581 1582 1583 1584
[1585] 1585 1586 1587 1588 1589 1590 1591 1592 1593 1594 1595 1596 1597 1598 1599 1600 1601 1602 1603 1604 1605 1606
[1607] 1607 1608 1609 1610 1611 1612 1613 1614 1615 1616 1617 1618 1619 1620 1621 1622 1623 1624 1625 1626 1627 1628
[1629] 1629 1630 1631 1632 1633 1634 1635 1636 1637 1638 1639 1640 1641 1642 1643 1644 1645 1646 1647 1648 1649 1650
[1651] 1651 1652 1653 1654 1655 1656 1657 1658 1659 1660 1661 1662 1663 1664 1665 1666 1667 1668 1669 1670 1671 1672
[1673] 1673 1674 1675 1676 1677 1678 1679 1680 1681 1682 1683 1684 1685 1686 1687 1688 1689 1690 1691 1692 1693 1694
[1695] 1695 1696 1697 1698 1699 1700 1701 1702 1703 1704 1705 1706 1707 1708 1709 1710 1711 1712 1713 1714 1715 1716
[1717] 1717 1718 1719 1720 1721 1722 1723 1724 1725 1726 1727 1728 1729 1730 1731 1732 1733 1734 1735 1736 1737 1738
[1739] 1739 1740 1741 1742 1743 1744 1745 1746 1747 1748 1749 1750 1751 1752 1753 1754 1755 1756 1757 1758 1759 1760
[1761] 1761 1762 1763 1764 1765 1766 1767 1768 1769 1770 1771 1772 1773 1774 1775 1776 1777 1778 1779 1780 1781 1782
[1783] 1783 1784 1785 1786 1787 1788 1789 1790 1791 1792 1793 1794 1795 1796 1797 1798 1799 1800 1801 1802 1803 1804
[1805] 1805 1806 1807 1808 1809 1810 1811 1812 1813 1814 1815 1816 1817 1818 1819 1820 1821 1822 1823 1824 1825 1826
[1827] 1827 1828 1829 1830 1831 1832 1833 1834 1835 1836 1837 1838 1839 1840 1841 1842 1843 1844 1845 1846 1847 1848
[1849] 1849 1850 1851 1852 1853 1854 1855 1856 1857 1858 1859 1860 1861 1862 1863 1864 1865 1866 1867 1868 1869 1870
[1871] 1871 1872 1873 1874 1875 1876 1877 1878 1879 1880 1881 1882 1883 1884 1885 1886 1887 1888 1889 1890 1891 1892
[1893] 1893 1894 1895 1896 1897 1898 1899 1900 1901 1902 1903 1904 1905 1906 1907 1908 1909 1910 1911 1912 1913 1914
[1915] 1915 1916 1917 1918 1919 1920 1921 1922 1923 1924 1925 1926 1927 1928 1929 1930 1931 1932 1933 1934 1935 1936
[1937] 1937 1938 1939 1940 1941 1942 1943 1944 1945 1946 1947 1948 1949 1950 1951 1952 1953 1954 1955 1956 1957 1958
[1959] 1959 1960 1961 1962 1963 1964 1965 1966 1967 1968 1969 1970 1971 1972 1973 1974 1975 1976 1977 1978 1979 1980
[1981] 1981 1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002
[2003] 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024
[2025] 2025 2026 2027 2028 2029 2030 2031 2032 2033 2034 2035 2036 2037 2038 2039 2040 2041 2042 2043 2044 2045 2046
[2047] 2047 2048 2049 2050 2051 2052 2053 2054 2055 2056 2057 2058 2059 2060 2061 2062 2063 2064 2065 2066 2067 2068
[2069] 2069 2070 2071 2072 2073 2074 2075 2076 2077 2078 2079 2080 2081 2082 2083 2084 2085 2086 2087 2088 2089 2090
[2091] 2091 2092 2093 2094 2095 2096 2097 2098 2099 2100 2101 2102 2103 2104 2105 2106 2107 2108 2109 2110 2111 2112
[2113] 2113 2114 2115 2116 2117 2118 2119 2120 2121 2122 2123 2124 2125 2126 2127 2128 2129 2130 2131 2132 2133 2134
[2135] 2135 2136 2137 2138 2139 2140 2141 2142 2143 2144 2145 2146 2147 2148 2149 2150 2151 2152 2153 2154 2155 2156
[2157] 2157 2158 2159 2160 2161 2162 2163 2164 2165 2166 2167 2168 2169 2170 2171 2172 2173 2174 2175 2176 2177 2178
[2179] 2179 2180 2181 2182 2183 2184 2185 2186 2187 2188 2189 2190 2191 2192 2193 2194 2195 2196 2197 2198 2199 2200
[2201] 2201 2202 2203 2204 2205 2206 2207 2208 2209 2210 2211 2212 2213 2214 2215 2216 2217 2218 2219 2220 2221 2222
[2223] 2223 2224 2225 2226 2227 2228 2229 2230 2231 2232 2233 2234 2235 2236 2237 2238 2239 2240 2241 2242 2243 2244
[2245] 2245 2246 2247 2248 2249 2250 2251 2252 2253 2254 2255 2256 2257 2258 2259 2260 2261 2262 2263 2264 2265 2266
[2267] 2267 2268 2269 2270 2271 2272 2273 2274 2275 2276 2277 2278 2279 2280 2281 2282 2283 2284 2285 2286 2287 2288
[2289] 2289 2290 2291 2292 2293 2294 2295 2296 2297 2298 2299 2300 2301 2302 2303 2304 2305 2306 2307 2308 2309 2310
[2311] 2311 2312 2313 2314 2315 2316 2317 2318 2319 2320 2321 2322 2323 2324 2325 2326 2327 2328 2329 2330 2331 2332
[2333] 2333 2334 2335 2336 2337 2338 2339 2340 2341 2342 2343 2344 2345 2346 2347 2348 2349 2350 2351 2352 2353 2354
[2355] 2355 2356 2357 2358 2359 2360 2361 2362 2363 2364 2365 2366 2367 2368 2369 2370 2371 2372 2373 2374 2375 2376
[2377] 2377 2378 2379 2380 2381 2382 2383 2384 2385 2386 2387 2388 2389 2390 2391 2392 2393 2394 2395 2396 2397 2398
[2399] 2399 2400 2401 2402 2403 2404 2405 2406 2407 2408 2409 2410 2411 2412 2413 2414 2415 2416 2417 2418 2419 2420
[2421] 2421 2422 2423 2424 2425 2426 2427 2428 2429 2430 2431 2432 2433 2434 2435 2436 2437 2438 2439 2440 2441 2442
[2443] 2443 2444 2445 2446 2447 2448 2449 2450 2451 2452 2453 2454 2455 2456 2457 2458 2459 2460 2461 2462 2463 2464
[2465] 2465 2466 2467 2468 2469 2470 2471 2472 2473 2474 2475 2476 2477 2478 2479 2480 2481 2482 2483 2484 2485 2486
[2487] 2487 2488 2489 2490 2491 2492 2493 2494 2495 2496 2497 2498 2499 2500 2501 2502 2503 2504 2505 2506 2507 2508
[2509] 2509 2510 2511 2512 2513 2514 2515 2516 2517 2518 2519 2520 2521 2522 2523 2524 2525 2526 2527 2528 2529 2530
[2531] 2531 2532 2533 2534 2535 2536 2537 2538 2539 2540 2541 2542 2543 2544 2545 2546 2547 2548 2549 2550 2551 2552
[2553] 2553 2554 2555 2556 2557 2558 2559 2560 2561 2562 2563 2564 2565 2566 2567 2568 2569 2570 2571 2572 2573 2574
[2575] 2575 2576 2577 2578 2579 2580 2581 2582 2583 2584 2585 2586 2587 2588 2589 2590 2591 2592 2593 2594 2595 2596
[2597] 2597 2598 2599 2600 2601 2602 2603 2604 2605 2606 2607 2608 2609 2610 2611 2612 2613 2614 2615 2616 2617 2618
[2619] 2619 2620 2621 2622 2623 2624 2625 2626 2627 2628 2629 2630 2631 2632 2633 2634 2635 2636 2637 2638 2639 2640
[2641] 2641 2642 2643 2644 2645 2646 2647 2648 2649 2650 2651 2652 2653 2654 2655 2656 2657 2658 2659 2660 2661 2662
[2663] 2663 2664 2665 2666 2667 2668 2669 2670 2671 2672 2673 2674 2675 2676 2677 2678 2679 2680 2681 2682 2683 2684
[2685] 2685 2686 2687 2688 2689 2690 2691 2692 2693 2694

$names
 [1] "person_id"                   "gender_concept_id"           "year_of_birth"
 [4] "month_of_birth"              "day_of_birth"                "birth_datetime"
 [7] "race_concept_id"             "ethnicity_concept_id"        "location_id"
[10] "provider_id"                 "care_site_id"                "person_source_value"
[13] "gender_source_value"         "gender_source_concept_id"    "race_source_value"
[16] "race_source_concept_id"      "ethnicity_source_value"      "ethnicity_source_concept_id"

$tbl_source

This is a local cdm source


$tbl_name
[1] "person"

$cdm_reference


── # OMOP CDM reference (local) of GiBleed ─────────────────────────────────────────────────────────────────────────────
• omop tables: care_site, cdm_source, concept_ancestor, concept_class, concept_relationship, concept_synonym, concept,
condition_era, condition_occurrence, cost, death, device_exposure, domain, dose_era, drug_era, drug_exposure,
drug_strength, fact_relationship, location, measurement, metadata, note_nlp, note, observation_period, observation,
payer_plan_period, person, procedure_occurrence, provider, relationship, source_to_concept_map, specimen, visit_detail,
visit_occurrence, vocabulary
• cohort tables: -
• achilles tables: -
• other tables: -

Connecting to a database from R (the DBI package)

In general the OMOP datasets that we will use won’t be locally, and they will on a database.

Database connections from R can be made using the DBI package.

Connect to postgres:

library(RPostgres)
db <- dbConnect(
  Postgres(),
  dbname = "...",
  host = "...",
  user = "...",
  password = "..."
)

Connecting to a database from R (the DBI package)

Connect to Sql server:

library(odbc)
db <- dbConnect(
  odbc(),
  Driver   = "ODBC Driver 18 for SQL Server",
  Server   = "...",
  Database = "...",
  UID      = "...",
  PWD      = "...",
  TrustServerCertificate = "yes",
  Port     = "..."
)

In this CDMConnector article you can see how to connect to the different supported DBMS.

Databases organisation

Databases are organised by schemas (blueprint or plan that defines how the data will be organised and structured within the database).

In general, OMOP databases have two schemas:

cdm schema: it contains all the tables of the cdm. Usually we only will have reading permission for this schema.
write schema: it is a place where we can store tables (like cohorts). We need writing permissions to this schema.

Create a local database

duckdb is a package that allows us to create local databases.

# name of the dataset
datasetName <- "GiBleed"

# name of the database file
dbdir <- here(paste0(datasetName, ".duckdb"))

# create empty database
con <- dbConnect(drv = duckdb(dbdir = dbdir))

# create local reference
cdm <- mockCdmFromDataset(datasetName = datasetName)

# copy local reference to connection
insertCdmTo(cdm = cdm, to = dbSource(con = con, writeSchema = "main"))

# disconnect
dbDisconnect(conn = con)

Let’s create our first cdm reference

# connect to the database
dbdir <- here("GiBleed.duckdb")
con <- dbConnect(drv = duckdb(dbdir = dbdir))
cdm <- cdmFromCon(con = con, cdmSchema = "main", writeSchema = "main")
cdm

── # OMOP CDM reference (duckdb) of Synthea ────────────────────────────────────────────────────────────────────────────

• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship,
location, care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source,
concept, vocabulary, domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor,
source_to_concept_map, drug_strength

• cohort tables: -

• achilles tables: -

• other tables: -

Access to tables of the cdm reference

cdm$person

# Source:   table<person> [?? x 18]
# Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
   person_id gender_concept_id year_of_birth month_of_birth day_of_birth birth_datetime      race_concept_id
       <int>             <int>         <int>          <int>        <int> <dttm>                        <int>
 1         6              8532          1963             12           31 1963-12-31 00:00:00            8516
 2       123              8507          1950              4           12 1950-04-12 00:00:00            8527
 3       129              8507          1974             10            7 1974-10-07 00:00:00            8527
 4        16              8532          1971             10           13 1971-10-13 00:00:00            8527
 5        65              8532          1967              3           31 1967-03-31 00:00:00            8516
 6        74              8532          1972              1            5 1972-01-05 00:00:00            8527
 7        42              8532          1909             11            2 1909-11-02 00:00:00            8527
 8       187              8507          1945              7           23 1945-07-23 00:00:00            8527
 9        18              8532          1965             11           17 1965-11-17 00:00:00            8527
10       111              8532          1975              5            2 1975-05-02 00:00:00            8527
# ℹ more rows
# ℹ 11 more variables: ethnicity_concept_id <int>, location_id <int>, provider_id <int>, care_site_id <int>,
#   person_source_value <chr>, gender_source_value <chr>, gender_source_concept_id <int>, race_source_value <chr>,
#   race_source_concept_id <int>, ethnicity_source_value <chr>, ethnicity_source_concept_id <int>

Read tables in GiBleed

Once we read a table we can operate with it and for example count the number of rows of person table.

cdm$person |>
  count()

# Source:   SQL [?? x 1]
# Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
      n
  <dbl>
1  2694

Operation with tidyverse

If you are familiarised with tidyverse you can use any of the usual dplyr commands in you database tables.

cdm$drug_exposure |>
  group_by(drug_concept_id) |>
  summarise(number_persons = n_distinct(person_id)) |>
  collect() |>
  arrange(desc(number_persons))

# A tibble: 113 × 2
   drug_concept_id number_persons
             <int>          <dbl>
 1        40213227           2660
 2         1127433           2580
 3        40213160           2140
 4         1713671           2021
 5        19059056           1927
 6         1118084           1844
 7        40213296           1737
 8        40213306           1560
 9         1127078           1428
10        40229134           1393
# ℹ 103 more rows

Database name

When we have a cdm object we can check which is the name of that database using:

cdmName(cdm)

[1] "Synthea"

In some cases we want to give a database a name that we want, this can be done at the connection stage:

cdm <- cdmFromCon(
  con = con, cdmSchema = "main", writeSchema = "main", cdmName = "GiBleed"
)

cdmName(cdm)

[1] "GiBleed"

Create a new table

Let’s say I want to subset the condition_occurrence table to a certain rows and certain columns and save it so I can later access it.

temporary table (default):

cdm$my_saved_table <- cdm$condition_occurrence |>
  filter(condition_concept_id == 4112343) |>
  select(person_id, condition_start_date) |>
  compute()
listSourceTables(cdm)

  [1] "care_site"                                  "cdm_source"
  [3] "concept"                                    "concept_ancestor"
  [5] "concept_class"                              "concept_relationship"
  [7] "concept_synonym"                            "condition_era"
  [9] "condition_occurrence"                       "cost"
 [11] "death"                                      "device_exposure"
 [13] "domain"                                     "dose_era"
 [15] "drug_era"                                   "drug_exposure"
 [17] "drug_strength"                              "fact_relationship"
 [19] "location"                                   "measurement"
 [21] "metadata"                                   "my_study_age_cohort"
 [23] "my_study_age_cohort_attrition"              "my_study_age_cohort_codelist"
 [25] "my_study_age_cohort_set"                    "my_study_aspirin"
 [27] "my_study_aspirin_attrition"                 "my_study_aspirin_codelist"
 [29] "my_study_aspirin_last"                      "my_study_aspirin_last_attrition"
 [31] "my_study_aspirin_last_codelist"             "my_study_aspirin_last_set"
 [33] "my_study_aspirin_set"                       "my_study_aspirin_strata"
 [35] "my_study_aspirin_strata_attrition"          "my_study_aspirin_strata_codelist"
 [37] "my_study_aspirin_strata_set"                "my_study_diclofenac"
 [39] "my_study_diclofenac_attrition"              "my_study_diclofenac_codelist"
 [41] "my_study_diclofenac_set"                    "my_study_ibuprofen"
 [43] "my_study_ibuprofen_attrition"               "my_study_ibuprofen_codelist"
 [45] "my_study_ibuprofen_death"                   "my_study_ibuprofen_death_attrition"
 [47] "my_study_ibuprofen_death_codelist"          "my_study_ibuprofen_death_set"
 [49] "my_study_ibuprofen_set"                     "my_study_ibuprofen_strata"
 [51] "my_study_ibuprofen_strata_attrition"        "my_study_ibuprofen_strata_codelist"
 [53] "my_study_ibuprofen_strata_set"              "my_study_ibuprofen_years"
 [55] "my_study_ibuprofen_years_attrition"         "my_study_ibuprofen_years_codelist"
 [57] "my_study_ibuprofen_years_set"               "my_study_intersection"
 [59] "my_study_intersection_attrition"            "my_study_intersection_codelist"
 [61] "my_study_intersection_set"                  "my_study_medications"
 [63] "my_study_medications_attrition"             "my_study_medications_codelist"
 [65] "my_study_medications_collapsed"             "my_study_medications_collapsed_attrition"
 [67] "my_study_medications_collapsed_codelist"    "my_study_medications_collapsed_set"
 [69] "my_study_medications_requirement"           "my_study_medications_requirement_attrition"
 [71] "my_study_medications_requirement_codelist"  "my_study_medications_requirement_set"
 [73] "my_study_medications_set"                   "my_study_medications_trimmed"
 [75] "my_study_medications_trimmed_attrition"     "my_study_medications_trimmed_codelist"
 [77] "my_study_medications_trimmed_set"           "my_study_mi"
 [79] "my_study_mi_attrition"                      "my_study_mi_codelist"
 [81] "my_study_mi_set"                            "my_study_og_028_1750928000"
 [83] "my_study_og_029_1750928000"                 "my_study_og_029_1750928000_attrition"
 [85] "my_study_og_029_1750928000_codelist"        "my_study_og_029_1750928000_set"
 [87] "my_study_og_057_1750928015"                 "my_study_og_058_1750928015"
 [89] "my_study_og_058_1750928015_attrition"       "my_study_og_058_1750928015_codelist"
 [91] "my_study_og_058_1750928015_set"             "my_study_og_077_1750928021"
 [93] "my_study_og_078_1750928021"                 "my_study_og_078_1750928021_attrition"
 [95] "my_study_og_078_1750928021_codelist"        "my_study_og_078_1750928021_set"
 [97] "my_study_og_097_1750928028"                 "my_study_og_098_1750928028"
 [99] "my_study_og_098_1750928028_attrition"       "my_study_og_098_1750928028_codelist"
[101] "my_study_og_098_1750928028_set"             "my_study_og_117_1750928033"
[103] "my_study_og_118_1750928033"                 "my_study_og_118_1750928033_attrition"
[105] "my_study_og_118_1750928033_codelist"        "my_study_og_118_1750928033_set"
[107] "my_study_og_137_1750928038"                 "my_study_og_138_1750928038"
[109] "my_study_og_138_1750928038_attrition"       "my_study_og_138_1750928038_codelist"
[111] "my_study_og_138_1750928038_set"             "my_study_og_176_1750928057"
[113] "my_study_og_177_1750928057"                 "my_study_og_177_1750928057_attrition"
[115] "my_study_og_177_1750928057_codelist"        "my_study_og_177_1750928057_set"
[117] "my_study_og_196_1750928061"                 "my_study_og_197_1750928061"
[119] "my_study_og_197_1750928061_attrition"       "my_study_og_197_1750928061_codelist"
[121] "my_study_og_197_1750928061_set"             "my_study_statins"
[123] "my_study_statins_attrition"                 "my_study_statins_codelist"
[125] "my_study_statins_set"                       "note"
[127] "note_nlp"                                   "observation"
[129] "observation_period"                         "payer_plan_period"
[131] "person"                                     "procedure_occurrence"
[133] "provider"                                   "relationship"
[135] "source_to_concept_map"                      "specimen"
[137] "test_conditions"                            "test_conditions_attrition"
[139] "test_conditions_codelist"                   "test_conditions_set"
[141] "test_medications"                           "test_medications_attrition"
[143] "test_medications_codelist"                  "test_medications_set"
[145] "test_new_sinusitis"                         "test_new_sinusitis_attrition"
[147] "test_new_sinusitis_codelist"                "test_new_sinusitis_set"
[149] "test_sinusitis"                             "test_sinusitis_attrition"
[151] "test_sinusitis_codelist"                    "test_sinusitis_set"
[153] "visit_detail"                               "visit_occurrence"
[155] "vocabulary"                                 "og_001_1750928373"

Create a new table

permanent table:

cdm$my_saved_table <- cdm$condition_occurrence |>
  filter(condition_concept_id == 4112343) |>
  select(person_id, condition_start_date) |>
  compute(name = "my_saved_table")
listSourceTables(cdm)

  [1] "care_site"                                  "cdm_source"
  [3] "concept"                                    "concept_ancestor"
  [5] "concept_class"                              "concept_relationship"
  [7] "concept_synonym"                            "condition_era"
  [9] "condition_occurrence"                       "cost"
 [11] "death"                                      "device_exposure"
 [13] "domain"                                     "dose_era"
 [15] "drug_era"                                   "drug_exposure"
 [17] "drug_strength"                              "fact_relationship"
 [19] "location"                                   "measurement"
 [21] "metadata"                                   "my_saved_table"
 [23] "my_study_age_cohort"                        "my_study_age_cohort_attrition"
 [25] "my_study_age_cohort_codelist"               "my_study_age_cohort_set"
 [27] "my_study_aspirin"                           "my_study_aspirin_attrition"
 [29] "my_study_aspirin_codelist"                  "my_study_aspirin_last"
 [31] "my_study_aspirin_last_attrition"            "my_study_aspirin_last_codelist"
 [33] "my_study_aspirin_last_set"                  "my_study_aspirin_set"
 [35] "my_study_aspirin_strata"                    "my_study_aspirin_strata_attrition"
 [37] "my_study_aspirin_strata_codelist"           "my_study_aspirin_strata_set"
 [39] "my_study_diclofenac"                        "my_study_diclofenac_attrition"
 [41] "my_study_diclofenac_codelist"               "my_study_diclofenac_set"
 [43] "my_study_ibuprofen"                         "my_study_ibuprofen_attrition"
 [45] "my_study_ibuprofen_codelist"                "my_study_ibuprofen_death"
 [47] "my_study_ibuprofen_death_attrition"         "my_study_ibuprofen_death_codelist"
 [49] "my_study_ibuprofen_death_set"               "my_study_ibuprofen_set"
 [51] "my_study_ibuprofen_strata"                  "my_study_ibuprofen_strata_attrition"
 [53] "my_study_ibuprofen_strata_codelist"         "my_study_ibuprofen_strata_set"
 [55] "my_study_ibuprofen_years"                   "my_study_ibuprofen_years_attrition"
 [57] "my_study_ibuprofen_years_codelist"          "my_study_ibuprofen_years_set"
 [59] "my_study_intersection"                      "my_study_intersection_attrition"
 [61] "my_study_intersection_codelist"             "my_study_intersection_set"
 [63] "my_study_medications"                       "my_study_medications_attrition"
 [65] "my_study_medications_codelist"              "my_study_medications_collapsed"
 [67] "my_study_medications_collapsed_attrition"   "my_study_medications_collapsed_codelist"
 [69] "my_study_medications_collapsed_set"         "my_study_medications_requirement"
 [71] "my_study_medications_requirement_attrition" "my_study_medications_requirement_codelist"
 [73] "my_study_medications_requirement_set"       "my_study_medications_set"
 [75] "my_study_medications_trimmed"               "my_study_medications_trimmed_attrition"
 [77] "my_study_medications_trimmed_codelist"      "my_study_medications_trimmed_set"
 [79] "my_study_mi"                                "my_study_mi_attrition"
 [81] "my_study_mi_codelist"                       "my_study_mi_set"
 [83] "my_study_og_028_1750928000"                 "my_study_og_029_1750928000"
 [85] "my_study_og_029_1750928000_attrition"       "my_study_og_029_1750928000_codelist"
 [87] "my_study_og_029_1750928000_set"             "my_study_og_057_1750928015"
 [89] "my_study_og_058_1750928015"                 "my_study_og_058_1750928015_attrition"
 [91] "my_study_og_058_1750928015_codelist"        "my_study_og_058_1750928015_set"
 [93] "my_study_og_077_1750928021"                 "my_study_og_078_1750928021"
 [95] "my_study_og_078_1750928021_attrition"       "my_study_og_078_1750928021_codelist"
 [97] "my_study_og_078_1750928021_set"             "my_study_og_097_1750928028"
 [99] "my_study_og_098_1750928028"                 "my_study_og_098_1750928028_attrition"
[101] "my_study_og_098_1750928028_codelist"        "my_study_og_098_1750928028_set"
[103] "my_study_og_117_1750928033"                 "my_study_og_118_1750928033"
[105] "my_study_og_118_1750928033_attrition"       "my_study_og_118_1750928033_codelist"
[107] "my_study_og_118_1750928033_set"             "my_study_og_137_1750928038"
[109] "my_study_og_138_1750928038"                 "my_study_og_138_1750928038_attrition"
[111] "my_study_og_138_1750928038_codelist"        "my_study_og_138_1750928038_set"
[113] "my_study_og_176_1750928057"                 "my_study_og_177_1750928057"
[115] "my_study_og_177_1750928057_attrition"       "my_study_og_177_1750928057_codelist"
[117] "my_study_og_177_1750928057_set"             "my_study_og_196_1750928061"
[119] "my_study_og_197_1750928061"                 "my_study_og_197_1750928061_attrition"
[121] "my_study_og_197_1750928061_codelist"        "my_study_og_197_1750928061_set"
[123] "my_study_statins"                           "my_study_statins_attrition"
[125] "my_study_statins_codelist"                  "my_study_statins_set"
[127] "note"                                       "note_nlp"
[129] "observation"                                "observation_period"
[131] "payer_plan_period"                          "person"
[133] "procedure_occurrence"                       "provider"
[135] "relationship"                               "source_to_concept_map"
[137] "specimen"                                   "test_conditions"
[139] "test_conditions_attrition"                  "test_conditions_codelist"
[141] "test_conditions_set"                        "test_medications"
[143] "test_medications_attrition"                 "test_medications_codelist"
[145] "test_medications_set"                       "test_new_sinusitis"
[147] "test_new_sinusitis_attrition"               "test_new_sinusitis_codelist"
[149] "test_new_sinusitis_set"                     "test_sinusitis"
[151] "test_sinusitis_attrition"                   "test_sinusitis_codelist"
[153] "test_sinusitis_set"                         "visit_detail"
[155] "visit_occurrence"                           "vocabulary"
[157] "og_001_1750928373"

Create a new table

cdm

── # OMOP CDM reference (duckdb) of GiBleed ────────────────────────────────────────────────────────────────────────────

• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship,
location, care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source,
concept, vocabulary, domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor,
source_to_concept_map, drug_strength

• cohort tables: -

• achilles tables: -

• other tables: my_saved_table

cdm$my_saved_table

# Source:   table<my_saved_table> [?? x 2]
# Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
   person_id condition_start_date
       <int> <date>
 1       263 2015-10-02
 2       439 1990-03-20
 3       449 1999-12-12
 4       515 1961-11-14
 5        17 1963-12-02
 6        30 1993-03-19
 7        90 1970-01-15
 8       116 1959-06-11
 9       137 2005-11-15
10       176 1986-10-08
# ℹ more rows

Drop an existing table

To drop an existing table:

Eliminate the table from the cdm object.
Eliminate the table from the database.

cdm <- dropSourceTable(cdm = cdm, name = "my_saved_table")
cdm

── # OMOP CDM reference (duckdb) of GiBleed ────────────────────────────────────────────────────────────────────────────

• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship,
location, care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source,
concept, vocabulary, domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor,
source_to_concept_map, drug_strength

• cohort tables: -

• achilles tables: -

• other tables: -

Drop an existing table

listSourceTables(cdm)

  [1] "care_site"                                  "cdm_source"
  [3] "concept"                                    "concept_ancestor"
  [5] "concept_class"                              "concept_relationship"
  [7] "concept_synonym"                            "condition_era"
  [9] "condition_occurrence"                       "cost"
 [11] "death"                                      "device_exposure"
 [13] "domain"                                     "dose_era"
 [15] "drug_era"                                   "drug_exposure"
 [17] "drug_strength"                              "fact_relationship"
 [19] "location"                                   "measurement"
 [21] "metadata"                                   "my_study_age_cohort"
 [23] "my_study_age_cohort_attrition"              "my_study_age_cohort_codelist"
 [25] "my_study_age_cohort_set"                    "my_study_aspirin"
 [27] "my_study_aspirin_attrition"                 "my_study_aspirin_codelist"
 [29] "my_study_aspirin_last"                      "my_study_aspirin_last_attrition"
 [31] "my_study_aspirin_last_codelist"             "my_study_aspirin_last_set"
 [33] "my_study_aspirin_set"                       "my_study_aspirin_strata"
 [35] "my_study_aspirin_strata_attrition"          "my_study_aspirin_strata_codelist"
 [37] "my_study_aspirin_strata_set"                "my_study_diclofenac"
 [39] "my_study_diclofenac_attrition"              "my_study_diclofenac_codelist"
 [41] "my_study_diclofenac_set"                    "my_study_ibuprofen"
 [43] "my_study_ibuprofen_attrition"               "my_study_ibuprofen_codelist"
 [45] "my_study_ibuprofen_death"                   "my_study_ibuprofen_death_attrition"
 [47] "my_study_ibuprofen_death_codelist"          "my_study_ibuprofen_death_set"
 [49] "my_study_ibuprofen_set"                     "my_study_ibuprofen_strata"
 [51] "my_study_ibuprofen_strata_attrition"        "my_study_ibuprofen_strata_codelist"
 [53] "my_study_ibuprofen_strata_set"              "my_study_ibuprofen_years"
 [55] "my_study_ibuprofen_years_attrition"         "my_study_ibuprofen_years_codelist"
 [57] "my_study_ibuprofen_years_set"               "my_study_intersection"
 [59] "my_study_intersection_attrition"            "my_study_intersection_codelist"
 [61] "my_study_intersection_set"                  "my_study_medications"
 [63] "my_study_medications_attrition"             "my_study_medications_codelist"
 [65] "my_study_medications_collapsed"             "my_study_medications_collapsed_attrition"
 [67] "my_study_medications_collapsed_codelist"    "my_study_medications_collapsed_set"
 [69] "my_study_medications_requirement"           "my_study_medications_requirement_attrition"
 [71] "my_study_medications_requirement_codelist"  "my_study_medications_requirement_set"
 [73] "my_study_medications_set"                   "my_study_medications_trimmed"
 [75] "my_study_medications_trimmed_attrition"     "my_study_medications_trimmed_codelist"
 [77] "my_study_medications_trimmed_set"           "my_study_mi"
 [79] "my_study_mi_attrition"                      "my_study_mi_codelist"
 [81] "my_study_mi_set"                            "my_study_og_028_1750928000"
 [83] "my_study_og_029_1750928000"                 "my_study_og_029_1750928000_attrition"
 [85] "my_study_og_029_1750928000_codelist"        "my_study_og_029_1750928000_set"
 [87] "my_study_og_057_1750928015"                 "my_study_og_058_1750928015"
 [89] "my_study_og_058_1750928015_attrition"       "my_study_og_058_1750928015_codelist"
 [91] "my_study_og_058_1750928015_set"             "my_study_og_077_1750928021"
 [93] "my_study_og_078_1750928021"                 "my_study_og_078_1750928021_attrition"
 [95] "my_study_og_078_1750928021_codelist"        "my_study_og_078_1750928021_set"
 [97] "my_study_og_097_1750928028"                 "my_study_og_098_1750928028"
 [99] "my_study_og_098_1750928028_attrition"       "my_study_og_098_1750928028_codelist"
[101] "my_study_og_098_1750928028_set"             "my_study_og_117_1750928033"
[103] "my_study_og_118_1750928033"                 "my_study_og_118_1750928033_attrition"
[105] "my_study_og_118_1750928033_codelist"        "my_study_og_118_1750928033_set"
[107] "my_study_og_137_1750928038"                 "my_study_og_138_1750928038"
[109] "my_study_og_138_1750928038_attrition"       "my_study_og_138_1750928038_codelist"
[111] "my_study_og_138_1750928038_set"             "my_study_og_176_1750928057"
[113] "my_study_og_177_1750928057"                 "my_study_og_177_1750928057_attrition"
[115] "my_study_og_177_1750928057_codelist"        "my_study_og_177_1750928057_set"
[117] "my_study_og_196_1750928061"                 "my_study_og_197_1750928061"
[119] "my_study_og_197_1750928061_attrition"       "my_study_og_197_1750928061_codelist"
[121] "my_study_og_197_1750928061_set"             "my_study_statins"
[123] "my_study_statins_attrition"                 "my_study_statins_codelist"
[125] "my_study_statins_set"                       "note"
[127] "note_nlp"                                   "observation"
[129] "observation_period"                         "payer_plan_period"
[131] "person"                                     "procedure_occurrence"
[133] "provider"                                   "relationship"
[135] "source_to_concept_map"                      "specimen"
[137] "test_conditions"                            "test_conditions_attrition"
[139] "test_conditions_codelist"                   "test_conditions_set"
[141] "test_medications"                           "test_medications_attrition"
[143] "test_medications_codelist"                  "test_medications_set"
[145] "test_new_sinusitis"                         "test_new_sinusitis_attrition"
[147] "test_new_sinusitis_codelist"                "test_new_sinusitis_set"
[149] "test_sinusitis"                             "test_sinusitis_attrition"
[151] "test_sinusitis_codelist"                    "test_sinusitis_set"
[153] "visit_detail"                               "visit_occurrence"
[155] "vocabulary"                                 "og_001_1750928373"

Drop an existing table

Let’s drop also the other table that we created:

cdm <- dropSourceTable(cdm = cdm, name = starts_with("og_"))
cdm

── # OMOP CDM reference (duckdb) of GiBleed ────────────────────────────────────────────────────────────────────────────

• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship,
location, care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source,
concept, vocabulary, domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor,
source_to_concept_map, drug_strength

• cohort tables: -

• achilles tables: -

• other tables: -

Drop an existing table

listSourceTables(cdm)

  [1] "care_site"                                  "cdm_source"
  [3] "concept"                                    "concept_ancestor"
  [5] "concept_class"                              "concept_relationship"
  [7] "concept_synonym"                            "condition_era"
  [9] "condition_occurrence"                       "cost"
 [11] "death"                                      "device_exposure"
 [13] "domain"                                     "dose_era"
 [15] "drug_era"                                   "drug_exposure"
 [17] "drug_strength"                              "fact_relationship"
 [19] "location"                                   "measurement"
 [21] "metadata"                                   "my_study_age_cohort"
 [23] "my_study_age_cohort_attrition"              "my_study_age_cohort_codelist"
 [25] "my_study_age_cohort_set"                    "my_study_aspirin"
 [27] "my_study_aspirin_attrition"                 "my_study_aspirin_codelist"
 [29] "my_study_aspirin_last"                      "my_study_aspirin_last_attrition"
 [31] "my_study_aspirin_last_codelist"             "my_study_aspirin_last_set"
 [33] "my_study_aspirin_set"                       "my_study_aspirin_strata"
 [35] "my_study_aspirin_strata_attrition"          "my_study_aspirin_strata_codelist"
 [37] "my_study_aspirin_strata_set"                "my_study_diclofenac"
 [39] "my_study_diclofenac_attrition"              "my_study_diclofenac_codelist"
 [41] "my_study_diclofenac_set"                    "my_study_ibuprofen"
 [43] "my_study_ibuprofen_attrition"               "my_study_ibuprofen_codelist"
 [45] "my_study_ibuprofen_death"                   "my_study_ibuprofen_death_attrition"
 [47] "my_study_ibuprofen_death_codelist"          "my_study_ibuprofen_death_set"
 [49] "my_study_ibuprofen_set"                     "my_study_ibuprofen_strata"
 [51] "my_study_ibuprofen_strata_attrition"        "my_study_ibuprofen_strata_codelist"
 [53] "my_study_ibuprofen_strata_set"              "my_study_ibuprofen_years"
 [55] "my_study_ibuprofen_years_attrition"         "my_study_ibuprofen_years_codelist"
 [57] "my_study_ibuprofen_years_set"               "my_study_intersection"
 [59] "my_study_intersection_attrition"            "my_study_intersection_codelist"
 [61] "my_study_intersection_set"                  "my_study_medications"
 [63] "my_study_medications_attrition"             "my_study_medications_codelist"
 [65] "my_study_medications_collapsed"             "my_study_medications_collapsed_attrition"
 [67] "my_study_medications_collapsed_codelist"    "my_study_medications_collapsed_set"
 [69] "my_study_medications_requirement"           "my_study_medications_requirement_attrition"
 [71] "my_study_medications_requirement_codelist"  "my_study_medications_requirement_set"
 [73] "my_study_medications_set"                   "my_study_medications_trimmed"
 [75] "my_study_medications_trimmed_attrition"     "my_study_medications_trimmed_codelist"
 [77] "my_study_medications_trimmed_set"           "my_study_mi"
 [79] "my_study_mi_attrition"                      "my_study_mi_codelist"
 [81] "my_study_mi_set"                            "my_study_og_028_1750928000"
 [83] "my_study_og_029_1750928000"                 "my_study_og_029_1750928000_attrition"
 [85] "my_study_og_029_1750928000_codelist"        "my_study_og_029_1750928000_set"
 [87] "my_study_og_057_1750928015"                 "my_study_og_058_1750928015"
 [89] "my_study_og_058_1750928015_attrition"       "my_study_og_058_1750928015_codelist"
 [91] "my_study_og_058_1750928015_set"             "my_study_og_077_1750928021"
 [93] "my_study_og_078_1750928021"                 "my_study_og_078_1750928021_attrition"
 [95] "my_study_og_078_1750928021_codelist"        "my_study_og_078_1750928021_set"
 [97] "my_study_og_097_1750928028"                 "my_study_og_098_1750928028"
 [99] "my_study_og_098_1750928028_attrition"       "my_study_og_098_1750928028_codelist"
[101] "my_study_og_098_1750928028_set"             "my_study_og_117_1750928033"
[103] "my_study_og_118_1750928033"                 "my_study_og_118_1750928033_attrition"
[105] "my_study_og_118_1750928033_codelist"        "my_study_og_118_1750928033_set"
[107] "my_study_og_137_1750928038"                 "my_study_og_138_1750928038"
[109] "my_study_og_138_1750928038_attrition"       "my_study_og_138_1750928038_codelist"
[111] "my_study_og_138_1750928038_set"             "my_study_og_176_1750928057"
[113] "my_study_og_177_1750928057"                 "my_study_og_177_1750928057_attrition"
[115] "my_study_og_177_1750928057_codelist"        "my_study_og_177_1750928057_set"
[117] "my_study_og_196_1750928061"                 "my_study_og_197_1750928061"
[119] "my_study_og_197_1750928061_attrition"       "my_study_og_197_1750928061_codelist"
[121] "my_study_og_197_1750928061_set"             "my_study_statins"
[123] "my_study_statins_attrition"                 "my_study_statins_codelist"
[125] "my_study_statins_set"                       "note"
[127] "note_nlp"                                   "observation"
[129] "observation_period"                         "payer_plan_period"
[131] "person"                                     "procedure_occurrence"
[133] "provider"                                   "relationship"
[135] "source_to_concept_map"                      "specimen"
[137] "test_conditions"                            "test_conditions_attrition"
[139] "test_conditions_codelist"                   "test_conditions_set"
[141] "test_medications"                           "test_medications_attrition"
[143] "test_medications_codelist"                  "test_medications_set"
[145] "test_new_sinusitis"                         "test_new_sinusitis_attrition"
[147] "test_new_sinusitis_codelist"                "test_new_sinusitis_set"
[149] "test_sinusitis"                             "test_sinusitis_attrition"
[151] "test_sinusitis_codelist"                    "test_sinusitis_set"
[153] "visit_detail"                               "visit_occurrence"
[155] "vocabulary"

Insert a table

Let’s say we have a local tibble and we want to insert it in the cdm:

cdm <- insertTable(cdm = cdm, name = "my_test_table", table = cars)
cdm

── # OMOP CDM reference (duckdb) of GiBleed ────────────────────────────────────────────────────────────────────────────

• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship,
location, care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source,
concept, vocabulary, domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor,
source_to_concept_map, drug_strength

• cohort tables: -

• achilles tables: -

• other tables: my_test_table

Insert a table

listSourceTables(cdm)

  [1] "care_site"                                  "cdm_source"
  [3] "concept"                                    "concept_ancestor"
  [5] "concept_class"                              "concept_relationship"
  [7] "concept_synonym"                            "condition_era"
  [9] "condition_occurrence"                       "cost"
 [11] "death"                                      "device_exposure"
 [13] "domain"                                     "dose_era"
 [15] "drug_era"                                   "drug_exposure"
 [17] "drug_strength"                              "fact_relationship"
 [19] "location"                                   "measurement"
 [21] "metadata"                                   "my_study_age_cohort"
 [23] "my_study_age_cohort_attrition"              "my_study_age_cohort_codelist"
 [25] "my_study_age_cohort_set"                    "my_study_aspirin"
 [27] "my_study_aspirin_attrition"                 "my_study_aspirin_codelist"
 [29] "my_study_aspirin_last"                      "my_study_aspirin_last_attrition"
 [31] "my_study_aspirin_last_codelist"             "my_study_aspirin_last_set"
 [33] "my_study_aspirin_set"                       "my_study_aspirin_strata"
 [35] "my_study_aspirin_strata_attrition"          "my_study_aspirin_strata_codelist"
 [37] "my_study_aspirin_strata_set"                "my_study_diclofenac"
 [39] "my_study_diclofenac_attrition"              "my_study_diclofenac_codelist"
 [41] "my_study_diclofenac_set"                    "my_study_ibuprofen"
 [43] "my_study_ibuprofen_attrition"               "my_study_ibuprofen_codelist"
 [45] "my_study_ibuprofen_death"                   "my_study_ibuprofen_death_attrition"
 [47] "my_study_ibuprofen_death_codelist"          "my_study_ibuprofen_death_set"
 [49] "my_study_ibuprofen_set"                     "my_study_ibuprofen_strata"
 [51] "my_study_ibuprofen_strata_attrition"        "my_study_ibuprofen_strata_codelist"
 [53] "my_study_ibuprofen_strata_set"              "my_study_ibuprofen_years"
 [55] "my_study_ibuprofen_years_attrition"         "my_study_ibuprofen_years_codelist"
 [57] "my_study_ibuprofen_years_set"               "my_study_intersection"
 [59] "my_study_intersection_attrition"            "my_study_intersection_codelist"
 [61] "my_study_intersection_set"                  "my_study_medications"
 [63] "my_study_medications_attrition"             "my_study_medications_codelist"
 [65] "my_study_medications_collapsed"             "my_study_medications_collapsed_attrition"
 [67] "my_study_medications_collapsed_codelist"    "my_study_medications_collapsed_set"
 [69] "my_study_medications_requirement"           "my_study_medications_requirement_attrition"
 [71] "my_study_medications_requirement_codelist"  "my_study_medications_requirement_set"
 [73] "my_study_medications_set"                   "my_study_medications_trimmed"
 [75] "my_study_medications_trimmed_attrition"     "my_study_medications_trimmed_codelist"
 [77] "my_study_medications_trimmed_set"           "my_study_mi"
 [79] "my_study_mi_attrition"                      "my_study_mi_codelist"
 [81] "my_study_mi_set"                            "my_study_og_028_1750928000"
 [83] "my_study_og_029_1750928000"                 "my_study_og_029_1750928000_attrition"
 [85] "my_study_og_029_1750928000_codelist"        "my_study_og_029_1750928000_set"
 [87] "my_study_og_057_1750928015"                 "my_study_og_058_1750928015"
 [89] "my_study_og_058_1750928015_attrition"       "my_study_og_058_1750928015_codelist"
 [91] "my_study_og_058_1750928015_set"             "my_study_og_077_1750928021"
 [93] "my_study_og_078_1750928021"                 "my_study_og_078_1750928021_attrition"
 [95] "my_study_og_078_1750928021_codelist"        "my_study_og_078_1750928021_set"
 [97] "my_study_og_097_1750928028"                 "my_study_og_098_1750928028"
 [99] "my_study_og_098_1750928028_attrition"       "my_study_og_098_1750928028_codelist"
[101] "my_study_og_098_1750928028_set"             "my_study_og_117_1750928033"
[103] "my_study_og_118_1750928033"                 "my_study_og_118_1750928033_attrition"
[105] "my_study_og_118_1750928033_codelist"        "my_study_og_118_1750928033_set"
[107] "my_study_og_137_1750928038"                 "my_study_og_138_1750928038"
[109] "my_study_og_138_1750928038_attrition"       "my_study_og_138_1750928038_codelist"
[111] "my_study_og_138_1750928038_set"             "my_study_og_176_1750928057"
[113] "my_study_og_177_1750928057"                 "my_study_og_177_1750928057_attrition"
[115] "my_study_og_177_1750928057_codelist"        "my_study_og_177_1750928057_set"
[117] "my_study_og_196_1750928061"                 "my_study_og_197_1750928061"
[119] "my_study_og_197_1750928061_attrition"       "my_study_og_197_1750928061_codelist"
[121] "my_study_og_197_1750928061_set"             "my_study_statins"
[123] "my_study_statins_attrition"                 "my_study_statins_codelist"
[125] "my_study_statins_set"                       "my_test_table"
[127] "note"                                       "note_nlp"
[129] "observation"                                "observation_period"
[131] "payer_plan_period"                          "person"
[133] "procedure_occurrence"                       "provider"
[135] "relationship"                               "source_to_concept_map"
[137] "specimen"                                   "test_conditions"
[139] "test_conditions_attrition"                  "test_conditions_codelist"
[141] "test_conditions_set"                        "test_medications"
[143] "test_medications_attrition"                 "test_medications_codelist"
[145] "test_medications_set"                       "test_new_sinusitis"
[147] "test_new_sinusitis_attrition"               "test_new_sinusitis_codelist"
[149] "test_new_sinusitis_set"                     "test_sinusitis"
[151] "test_sinusitis_attrition"                   "test_sinusitis_codelist"
[153] "test_sinusitis_set"                         "visit_detail"
[155] "visit_occurrence"                           "vocabulary"

cdm$my_test_table

# Source:   table<my_test_table> [?? x 2]
# Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
   speed  dist
   <dbl> <dbl>
 1     4     2
 2     4    10
 3     7     4
 4     7    22
 5     8    16
 6     9    10
 7    10    18
 8    10    26
 9    10    34
10    11    17
# ℹ more rows

Use a prefix

It is VERY IMPORTANT that when we create the cdm object we use a prefix:

cdm <- cdmFromCon(
  con = con,
  cdmSchema = "main",
  writeSchema = "main",
  writePrefix = "my_prefix_"
)
cdm

── # OMOP CDM reference (duckdb) of Synthea ────────────────────────────────────────────────────────────────────────────

• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship,
location, care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source,
concept, vocabulary, domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor,
source_to_concept_map, drug_strength

• cohort tables: -

• achilles tables: -

• other tables: -

Use a prefix

Now when we create a new table the prefix will be automatically added:

cdm <- insertTable(cdm = cdm, name = "my_test_table", table = cars)
cdm

── # OMOP CDM reference (duckdb) of Synthea ────────────────────────────────────────────────────────────────────────────

• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship,
location, care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source,
concept, vocabulary, domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor,
source_to_concept_map, drug_strength

• cohort tables: -

• achilles tables: -

• other tables: my_test_table

Use a prefix

listSourceTables(cdm = cdm)

[1] "my_test_table"

cdm$my_test_table

# Source:   table<my_prefix_my_test_table> [?? x 2]
# Database: DuckDB v1.3.1 [unknown@Linux 6.11.0-1015-azure:R 4.5.1//home/runner/work/RealWorldEvidenceSummerSchool2025/RealWorldEvidenceSummerSchool2025/GiBleed.duckdb]
   speed  dist
   <dbl> <dbl>
 1     4     2
 2     4    10
 3     7     4
 4     7    22
 5     8    16
 6     9    10
 7    10    18
 8    10    26
 9    10    34
10    11    17
# ℹ more rows

Use a prefix

DO NOT use the prefix to drop tables, you only care about the prefix at the connection stage!

cdm <- dropSourceTable(cdm = cdm, name = "my_prefix_my_test_table")
listSourceTables(cdm = cdm)

[1] "my_test_table"

Use a prefix

cdm

── # OMOP CDM reference (duckdb) of Synthea ────────────────────────────────────────────────────────────────────────────

• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship,
location, care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source,
concept, vocabulary, domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor,
source_to_concept_map, drug_strength

• cohort tables: -

• achilles tables: -

• other tables: my_test_table

Use a prefix

DO NOT use the prefix to drop tables, you only care about the prefix at the connection stage!

cdm <- dropSourceTable(cdm = cdm, name = "my_test_table")
listSourceTables(cdm = cdm)

character(0)

Use a prefix

cdm

── # OMOP CDM reference (duckdb) of Synthea ────────────────────────────────────────────────────────────────────────────

• omop tables: person, observation_period, visit_occurrence, visit_detail, condition_occurrence, drug_exposure,
procedure_occurrence, device_exposure, measurement, observation, death, note, note_nlp, specimen, fact_relationship,
location, care_site, provider, payer_plan_period, cost, drug_era, dose_era, condition_era, metadata, cdm_source,
concept, vocabulary, domain, concept_class, concept_relationship, relationship, concept_synonym, concept_ancestor,
source_to_concept_map, drug_strength

• cohort tables: -

• achilles tables: -

• other tables: -

Consistency rules

We use compute() to compute the result into a temporary (temporary = TRUE) or permanent (temporary = FALSE) table.

If it is a temporary table we can assign assign it to where I want for example:

cdm$my_custom_name <- cdm$person |>
  compute()

If it is a permanent table we can only assign it to the same name:

error:

cdm$my_custom_name <- cdm$person |>
  compute(name = "not_my_custom_name")

Error in `[[<-`:
! You can't assign a table named not_my_custom_name to my_custom_name. Please use compute to change table name.

no error:

cdm$my_custom_name <- cdm$person |>
  compute(name = "my_custom_name")

Consistency rules

Omop names are reserved words, e.g. we can not assign a table that is not the person table to cdm$person.

cdm$person <- cdm$drug_exposure |>
  compute(name = "person", temporary = FALSE)

Error in `newOmopTable()`:
! gender_concept_id, year_of_birth, race_concept_id and ethnicity_concept_id are not present in table person

cdm$drug_exposure <- cdm$drug_exposure |>
  rename("my_id" = "person_id") |>
  compute(name = "drug_exposure", temporary = FALSE)

Error in `newOmopTable()`:
! person_id is not present in table drug_exposure

Result model

The output of our analyses has been standardised to the <summarised_result> object.

x <- mockSummarisedResult()
x

# A tibble: 126 × 13
   result_id cdm_name group_name  group_level strata_name       strata_level  variable_name variable_level estimate_name
       <int> <chr>    <chr>       <chr>       <chr>             <chr>         <chr>         <chr>          <chr>
 1         1 mock     cohort_name cohort1     overall           overall       number subje… <NA>           count
 2         1 mock     cohort_name cohort1     age_group &&& sex <40 &&& Male  number subje… <NA>           count
 3         1 mock     cohort_name cohort1     age_group &&& sex >=40 &&& Male number subje… <NA>           count
 4         1 mock     cohort_name cohort1     age_group &&& sex <40 &&& Fema… number subje… <NA>           count
 5         1 mock     cohort_name cohort1     age_group &&& sex >=40 &&& Fem… number subje… <NA>           count
 6         1 mock     cohort_name cohort1     sex               Male          number subje… <NA>           count
 7         1 mock     cohort_name cohort1     sex               Female        number subje… <NA>           count
 8         1 mock     cohort_name cohort1     age_group         <40           number subje… <NA>           count
 9         1 mock     cohort_name cohort1     age_group         >=40          number subje… <NA>           count
10         1 mock     cohort_name cohort2     overall           overall       number subje… <NA>           count
# ℹ 116 more rows
# ℹ 4 more variables: estimate_type <chr>, estimate_value <chr>, additional_name <chr>, additional_level <chr>

class(x)

[1] "summarised_result" "omop_result"       "tbl_df"            "tbl"               "data.frame"

`<summarised_result>`

The summarised result object contains 13 columns:

glimpse(x)

Rows: 126
Columns: 13
$ result_id        <int> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, …
$ cdm_name         <chr> "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock…
$ group_name       <chr> "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "co…
$ group_level      <chr> "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "coho…
$ strata_name      <chr> "overall", "age_group &&& sex", "age_group &&& sex", "age_group &&& sex", "age_group &&& sex"…
$ strata_level     <chr> "overall", "<40 &&& Male", ">=40 &&& Male", "<40 &&& Female", ">=40 &&& Female", "Male", "Fem…
$ variable_name    <chr> "number subjects", "number subjects", "number subjects", "number subjects", "number subjects"…
$ variable_level   <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, N…
$ estimate_name    <chr> "count", "count", "count", "count", "count", "count", "count", "count", "count", "count", "co…
$ estimate_type    <chr> "integer", "integer", "integer", "integer", "integer", "integer", "integer", "integer", "inte…
$ estimate_value   <chr> "2655087", "3721239", "5728534", "9082078", "2016819", "8983897", "9446753", "6607978", "6291…
$ additional_name  <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…
$ additional_level <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…

`<summarised_result>`

And have some associated settings

settings(x)

# A tibble: 1 × 8
  result_id result_type            package_name   package_version group       strata           additional min_cell_count
      <int> <chr>                  <chr>          <chr>           <chr>       <chr>            <chr>      <chr>
1         1 mock_summarised_result visOmopResults 1.1.1           cohort_name age_group &&& s… ""         0

tidy the result object

x |>
  splitGroup() |>
  glimpse()

Rows: 126
Columns: 12
$ result_id        <int> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, …
$ cdm_name         <chr> "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock…
$ cohort_name      <chr> "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "coho…
$ strata_name      <chr> "overall", "age_group &&& sex", "age_group &&& sex", "age_group &&& sex", "age_group &&& sex"…
$ strata_level     <chr> "overall", "<40 &&& Male", ">=40 &&& Male", "<40 &&& Female", ">=40 &&& Female", "Male", "Fem…
$ variable_name    <chr> "number subjects", "number subjects", "number subjects", "number subjects", "number subjects"…
$ variable_level   <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, N…
$ estimate_name    <chr> "count", "count", "count", "count", "count", "count", "count", "count", "count", "count", "co…
$ estimate_type    <chr> "integer", "integer", "integer", "integer", "integer", "integer", "integer", "integer", "inte…
$ estimate_value   <chr> "2655087", "3721239", "5728534", "9082078", "2016819", "8983897", "9446753", "6607978", "6291…
$ additional_name  <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…
$ additional_level <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…

tidy the result object

x |>
  splitStrata() |>
  glimpse()

Rows: 126
Columns: 13
$ result_id        <int> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, …
$ cdm_name         <chr> "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock…
$ group_name       <chr> "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "co…
$ group_level      <chr> "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "coho…
$ age_group        <chr> "overall", "<40", ">=40", "<40", ">=40", "overall", "overall", "<40", ">=40", "overall", "<40…
$ sex              <chr> "overall", "Male", "Male", "Female", "Female", "Male", "Female", "overall", "overall", "overa…
$ variable_name    <chr> "number subjects", "number subjects", "number subjects", "number subjects", "number subjects"…
$ variable_level   <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, N…
$ estimate_name    <chr> "count", "count", "count", "count", "count", "count", "count", "count", "count", "count", "co…
$ estimate_type    <chr> "integer", "integer", "integer", "integer", "integer", "integer", "integer", "integer", "inte…
$ estimate_value   <chr> "2655087", "3721239", "5728534", "9082078", "2016819", "8983897", "9446753", "6607978", "6291…
$ additional_name  <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…
$ additional_level <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…

tidy the result object

x |>
  splitAdditional() |>
  glimpse()

Rows: 126
Columns: 11
$ result_id      <int> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1,…
$ cdm_name       <chr> "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock",…
$ group_name     <chr> "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "coho…
$ group_level    <chr> "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort…
$ strata_name    <chr> "overall", "age_group &&& sex", "age_group &&& sex", "age_group &&& sex", "age_group &&& sex", …
$ strata_level   <chr> "overall", "<40 &&& Male", ">=40 &&& Male", "<40 &&& Female", ">=40 &&& Female", "Male", "Femal…
$ variable_name  <chr> "number subjects", "number subjects", "number subjects", "number subjects", "number subjects", …
$ variable_level <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
$ estimate_name  <chr> "count", "count", "count", "count", "count", "count", "count", "count", "count", "count", "coun…
$ estimate_type  <chr> "integer", "integer", "integer", "integer", "integer", "integer", "integer", "integer", "intege…
$ estimate_value <chr> "2655087", "3721239", "5728534", "9082078", "2016819", "8983897", "9446753", "6607978", "629114…

tidy the result object

x |>
  pivotEstimates() |>
  glimpse()

Rows: 72
Columns: 14
$ result_id        <int> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, …
$ cdm_name         <chr> "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock…
$ group_name       <chr> "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "co…
$ group_level      <chr> "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "coho…
$ strata_name      <chr> "overall", "age_group &&& sex", "age_group &&& sex", "age_group &&& sex", "age_group &&& sex"…
$ strata_level     <chr> "overall", "<40 &&& Male", ">=40 &&& Male", "<40 &&& Female", ">=40 &&& Female", "Male", "Fem…
$ variable_name    <chr> "number subjects", "number subjects", "number subjects", "number subjects", "number subjects"…
$ variable_level   <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, N…
$ additional_name  <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…
$ additional_level <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…
$ count            <int> 2655087, 3721239, 5728534, 9082078, 2016819, 8983897, 9446753, 6607978, 6291140, 617863, 2059…
$ mean             <dbl> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, 38.003518, 77.744522,…
$ sd               <dbl> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, 7.942399, 1.079436, 7…
$ percentage       <dbl> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, N…

tidy the result object

x |>
  tidy() |>
  glimpse()

Rows: 72
Columns: 10
$ cdm_name       <chr> "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock",…
$ cohort_name    <chr> "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort1", "cohort…
$ age_group      <chr> "overall", "<40", ">=40", "<40", ">=40", "overall", "overall", "<40", ">=40", "overall", "<40",…
$ sex            <chr> "overall", "Male", "Male", "Female", "Female", "Male", "Female", "overall", "overall", "overall…
$ variable_name  <chr> "number subjects", "number subjects", "number subjects", "number subjects", "number subjects", …
$ variable_level <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
$ count          <int> 2655087, 3721239, 5728534, 9082078, 2016819, 8983897, 9446753, 6607978, 6291140, 617863, 205974…
$ mean           <dbl> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, 38.003518, 77.744522, 9…
$ sd             <dbl> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, 7.942399, 1.079436, 7.2…
$ percentage     <dbl> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…

filtering the result object

x |>
  filter(strata_name == "overall") |>
  glimpse()

Rows: 14
Columns: 13
$ result_id        <int> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1
$ cdm_name         <chr> "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock…
$ group_name       <chr> "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "co…
$ group_level      <chr> "cohort1", "cohort2", "cohort1", "cohort2", "cohort1", "cohort2", "cohort1", "cohort2", "coho…
$ strata_name      <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…
$ strata_level     <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…
$ variable_name    <chr> "number subjects", "number subjects", "age", "age", "age", "age", "Medications", "Medications…
$ variable_level   <chr> NA, NA, NA, NA, NA, NA, "Amoxiciline", "Amoxiciline", "Amoxiciline", "Amoxiciline", "Ibuprofe…
$ estimate_name    <chr> "count", "count", "mean", "mean", "sd", "sd", "count", "count", "percentage", "percentage", "…
$ estimate_type    <chr> "integer", "integer", "numeric", "numeric", "numeric", "numeric", "integer", "integer", "perc…
$ estimate_value   <chr> "2655087", "617863", "38.0035179434344", "38.2387957070023", "7.9423986072652", "7.8935623168…
$ additional_name  <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…
$ additional_level <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…

filtering the result object

x |>
  filterStrata(sex == "Female") |>
  glimpse()

Rows: 42
Columns: 13
$ result_id        <int> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, …
$ cdm_name         <chr> "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock", "mock…
$ group_name       <chr> "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "cohort_name", "co…
$ group_level      <chr> "cohort1", "cohort1", "cohort1", "cohort2", "cohort2", "cohort2", "cohort1", "cohort1", "coho…
$ strata_name      <chr> "age_group &&& sex", "age_group &&& sex", "sex", "age_group &&& sex", "age_group &&& sex", "s…
$ strata_level     <chr> "<40 &&& Female", ">=40 &&& Female", "Female", "<40 &&& Female", ">=40 &&& Female", "Female",…
$ variable_name    <chr> "number subjects", "number subjects", "number subjects", "number subjects", "number subjects"…
$ variable_level   <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, "Amoxiciline", "Amoxi…
$ estimate_name    <chr> "count", "count", "count", "count", "count", "count", "mean", "mean", "mean", "mean", "mean",…
$ estimate_type    <chr> "integer", "integer", "integer", "integer", "integer", "integer", "numeric", "numeric", "nume…
$ estimate_value   <chr> "9082078", "2016819", "9446753", "6870228", "3841037", "4976992", "21.2142521282658", "65.167…
$ additional_name  <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…
$ additional_level <chr> "overall", "overall", "overall", "overall", "overall", "overall", "overall", "overall", "over…

Other objects and classes

<codelist>, <codelist_with_details>, <conceptSetExpression>
<cohort_table>
<achilles_table>

omock

👉 Packages website
👉 CRAN link
👉 Manual

📧 mike.du@ndorms.ox.ac.uk

omopgenerics

👉 Packages website
👉 CRAN link
👉 Manual

📧 marti.catalasabate@ndorms.ox.ac.uk

visOmopResults

👉 Packages website
👉 CRAN link
👉 Manual

📧 nuria.mercadebesora@ndorms.ox.ac.uk

CDMConnector

👉 Packages website
👉 CRAN link
👉 Manual

📧 marti.catalasabate@ndorms.ox.ac.uk

OMOP and CDMConnector

Introduction: The OMOP Common Data Model

Standarisation of the data format

Mapping a database to the OMOP CDM

Mapping a database to the OMOP CDM

Mapping a database to the OMOP CDM

Standarisation of the vocabularies

Example of mapping

Example of mapping

Example of mapping

Example of mapping

More details

Let’s start coding

Create a mock reference

<cdm_reference> object

<cdm_reference> object

<cdm_table> object

<cdm_table> object

<cdm_table> object

<cdm_table> object

Connecting to a database from R (the DBI package)

Connecting to a database from R (the DBI package)

Databases organisation

Create a local database

Let’s create our first cdm reference

Access to tables of the cdm reference

Read tables in GiBleed

Operation with tidyverse

Database name

Create a new table

Create a new table

Create a new table

Drop an existing table

Drop an existing table

Drop an existing table

Drop an existing table

Insert a table

Insert a table

Use a prefix

Use a prefix

Use a prefix

Use a prefix

Use a prefix

Use a prefix

Use a prefix

Consistency rules

Consistency rules

Result model

<summarised_result>

<summarised_result>

tidy the result object

tidy the result object

tidy the result object

tidy the result object

tidy the result object

filtering the result object

filtering the result object

Other objects and classes

omock

omopgenerics

visOmopResults

CDMConnector

`<cdm_reference>` object

`<cdm_reference>` object

`<cdm_table>` object

`<cdm_table>` object

`<cdm_table>` object

`<cdm_table>` object

`<summarised_result>`

`<summarised_result>`
